| 主(zhu)要(yao)技術參數 | TECHNICAL DATA | UNIT | YP12090 |
| 最大(da)壓制(zhi)力 | Max.Pressing Force | kN | 120000 |
| 最大頂出力 | Max.Ejecting Force | kN | 400 |
| 動梁最大行程 | Max.Plunger Stroke | mm | 220 |
| 動梁下平面與工(gong)作臺面最小間距 | Min.Distance between Press Plunger and Table | mm | 580 |
| 動梁下平面(mian)與工作臺(tai)面(mian)最大間距 | Max.Distance between Press Plunger and Table | mm | 800 |
| 左右(you)立柱(zhu)間凈空 | Clearance between Columns | mm | 3030 |
| 動梁工作面前后(hou)寬度 | Useful Width of Plunger | mm | 1400 |
| 工(gong)作臺面(mian)前后寬(kuan)度 | Width of Press Table | mm | 1620 |
| 最大填料深度 | Max.Filling Depth | mm | 80 |
| 空循環(huan)次數可達 | Working Cycles in idle Stroke | mm-1 | 14 |
| 周期(qi)中加壓次數 | Strokes Per Cycle | times | 2～5 |
| 主(zhu)電機功率(lv) | Power of the Main Motor | kW | 220 |
| 系統(tong)裝(zhuang)油量 | System Oil Capacity | L | 3800 |
| 系統(tong)耗氣量 | Air Consumption | m3/h | 0.5 |
| 常溫水流(liu)量 | Water Consumption at 24℃ | m3/h | 45 |
| 主機重量(liang) | Weight of the Press Body | t | 340 |
